8. llama.cpp: best low-level control tool#

8.1 What it is#

llama.cpp is a C/C++ inference engine for running LLMs locally, especially GGUF models. It supports many backends including Metal, CUDA, HIP/ROCm, Vulkan, SYCL, OpenCL, WebGPU, CPU backends, and more.

Use llama.cpp when you want to understand what is really happening under the hood.

8.2 Installation#

macOS/Linux with Homebrew:

brew install llama.cpp

Windows:

winget install llama.cpp

Build from source:

git clone https://github.com/ggml-org/llama.cpp
cd llama.cpp

# CPU build
cmake -B build
cmake --build build --config Release -j

# NVIDIA CUDA build
cmake -B build -DGGML_CUDA=ON
cmake --build build --config Release -j

llama.cpp can be installed through brew, winget, prebuilt binaries, Docker, or source build.

8.3 Where files go#

llama.cpp does not force a model directory. A good structure:

~/models/
├── qwen/
│   └── qwen.Q4_K_M.gguf
├── llama/
│   └── llama.Q5_K_M.gguf
└── embeddings/
    └── embed.gguf

When using Hugging Face download mode, llama.cpp can download and cache compatible models; Hugging Face notes that the LLAMA_CACHE environment variable controls that cache location.

export LLAMA_CACHE="/data/llama-cache"

8.4 Run a GGUF model#

llama-cli \
  -m ~/models/qwen/qwen.Q4_K_M.gguf \
  -p "Explain recursion with a Python example." \
  -n 300

Conversation mode:

llama-cli -m ~/models/qwen/qwen.Q4_K_M.gguf -cnv

Run from Hugging Face directly:

llama-cli -hf bartowski/Llama-3.2-3B-Instruct-GGUF:Q8_0

llama.cpp supports llama-cli -hf ... and can run GGUF models directly from Hugging Face-compatible repos.

8.5 Start local API server#

llama-server \
  -m ~/models/qwen/qwen.Q4_K_M.gguf \
  --host 127.0.0.1 \
  --port 8080 \
  --ctx-size 8192

Call it:

curl http://localhost:8080/v1/chat/completions \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer no-key" \
  -d '{
    "messages": [
      {"role": "system", "content": "You are a helpful assistant."},
      {"role": "user", "content": "Explain Linux pipes."}
    ],
    "temperature": 0.2
  }'

llama.cpp’s llama-server is a lightweight OpenAI-compatible HTTP server, defaults to port 8080, and exposes /v1/chat/completions.

8.6 Important performance flags#

llama-server \
  -m model.gguf \
  --ctx-size 8192 \
  --threads 8 \
  --batch-size 512 \
  -ngl 999

Meaning:

--ctx-size     context window
--threads      CPU threads
--batch-size   prompt processing batch size
-ngl           number of layers offloaded to GPU

Common GPU offload pattern:

-ngl 999

This means “try to offload as many layers as possible.”

8.7 Quantization and conversion#

Typical workflow:

# Convert Hugging Face model to GGUF
python convert_hf_to_gguf.py /path/to/hf-model --outfile model-f16.gguf

# Quantize
llama-quantize model-f16.gguf model-q4_k_m.gguf Q4_K_M
llama-quantize model-f16.gguf model-q5_k_m.gguf Q5_K_M
llama-quantize model-f16.gguf model-q8_0.gguf Q8_0

Hugging Face says PyTorch models can be converted to GGUF, and llama.cpp’s repository points to tools for converting and quantizing models.

8.8 Grammar / JSON-constrained output#

llama.cpp supports grammar-constrained output. This is useful when you need valid JSON.

llama-cli \
  -m model.gguf \
  --grammar-file grammars/json.gbnf \
  -p 'Extract name and skills from: Riya knows Python and Docker.'

llama.cpp docs show grammar-constrained output and JSON grammar examples.

8.9 Embeddings and reranking#

Serve an embedding model:

llama-server \
  -m embedding-model.gguf \
  --embedding \
  --pooling cls \
  --port 8081

Serve a reranker:

llama-server \
  -m reranker-model.gguf \
  --reranking \
  --port 8082

llama.cpp’s server supports embedding and reranking modes.

8.10 Benchmarking#

llama-bench -m model.gguf

Compare:

model size
quantization
tokens/sec
prompt processing speed
RAM/VRAM use
answer quality

8.11 Clean uninstall#

Homebrew:

brew uninstall llama.cpp

Winget:

winget uninstall llama.cpp

Source build:

rm -rf ~/path/to/llama.cpp

Delete models only if desired:

rm -rf ~/models
rm -rf ~/.cache/huggingface/hub
rm -rf "$LLAMA_CACHE"

8.12 Real developer uses#

Use llama.cpp for:

- Running GGUF files directly
- CPU-only inference
- Edge devices
- Offline internal tools
- Quantization experiments
- Grammar-constrained JSON
- Embeddings/reranking
- Understanding GPU offload and context tradeoffs
- Building custom C/C++ integrations

8.13 Pros and cons#

Pros:

- Maximum control
- Excellent GGUF support
- Many hardware backends
- Great for offline use
- Great for learning internals

Cons:

- More manual setup
- You manage models, templates, flags, and performance
- Less beginner-friendly than LM Studio/Ollama

Recommended video: Quantize any LLM with GGUF and Llama.cpp.

9. vLLM: production inference server#

9.1 What it is#

vLLM is for high-throughput and memory-efficient LLM serving. It includes PagedAttention, continuous batching, chunked prefill, prefix caching, quantization support, OpenAI-compatible serving, streaming, tool-calling/reasoning parsers, distributed inference, and support for many hardware backends.

Use vLLM when you need:

Many users
High GPU utilization
OpenAI-compatible production API
Batching
Monitoring
Docker/Kubernetes deployment
Large model serving

9.2 Installation#

Recommended Python environment:

uv venv --python 3.12 --seed
source .venv/bin/activate
uv pip install vllm --torch-backend=auto

vLLM’s quickstart recommends uv, supports Python 3.10–3.13 on Linux, and shows uv pip install vllm --torch-backend=auto.

Quick temporary command:

uv run --with vllm vllm --help

9.3 Where files go#

vLLM is installed inside:

.venv/

or inside a Docker image.

Models usually download to:

~/.cache/huggingface/hub

For servers, mount the cache:

-v ~/.cache/huggingface:/root/.cache/huggingface

9.4 Start a local server#

vllm serve Qwen/Qwen2.5-1.5B-Instruct \
  --host 0.0.0.0 \
  --port 8000

Then:

curl http://localhost:8000/v1/models

vLLM starts an OpenAI-compatible server on localhost:8000 by default, and --host / --port can change it.

9.5 Chat completions#

curl http://localhost:8000/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{
    "model": "Qwen/Qwen2.5-1.5B-Instruct",
    "messages": [
      {"role": "system", "content": "You are a helpful backend engineer."},
      {"role": "user", "content": "Explain reverse proxy."}
    ],
    "temperature": 0.2
  }'

Python:

from openai import OpenAI

client = OpenAI(
    base_url="http://localhost:8000/v1",
    api_key="EMPTY"
)

response = client.chat.completions.create(
    model="Qwen/Qwen2.5-1.5B-Instruct",
    messages=[
        {"role": "user", "content": "Explain load balancing."}
    ],
)

print(response.choices[0].message.content)

vLLM is designed to work with OpenAI completions and chat completions APIs.

9.6 Docker deployment#

docker run --runtime nvidia --gpus all \
  -v ~/.cache/huggingface:/root/.cache/huggingface \
  --env "HF_TOKEN=$HF_TOKEN" \
  -p 8000:8000 \
  --ipc=host \
  vllm/vllm-openai:latest \
  --model Qwen/Qwen3-0.6B

vLLM provides official Docker images such as vllm/vllm-openai, and the docs recommend --ipc=host or shared memory configuration because PyTorch uses shared memory for tensor-parallel inference.

9.7 Add API key#

vllm serve Qwen/Qwen2.5-1.5B-Instruct \
  --host 0.0.0.0 \
  --port 8000 \
  --api-key "my-secret-key"

Then request:

curl http://localhost:8000/v1/chat/completions \
  -H "Authorization: Bearer my-secret-key" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "Qwen/Qwen2.5-1.5B-Instruct",
    "messages": [{"role": "user", "content": "Hello"}]
  }'

vLLM supports --api-key and VLLM_API_KEY for API-key checking.

9.8 Offline batch inference#

Use vLLM directly inside Python when you have many prompts:

from vllm import LLM, SamplingParams

prompts = [
    "Explain Docker.",
    "Explain Kubernetes.",
    "Explain Redis.",
]

sampling_params = SamplingParams(
    temperature=0.2,
    top_p=0.95,
    max_tokens=200,
)

llm = LLM(model="Qwen/Qwen2.5-1.5B-Instruct")
outputs = llm.generate(prompts, sampling_params)

for output in outputs:
    print(output.outputs[0].text)

vLLM’s quickstart covers offline batched inference using LLM and SamplingParams.

9.9 Production concepts to teach deeply#

Continuous batching#

Normal server:

Request 1 waits
Request 2 waits
Request 3 waits

vLLM-style serving:

Requests are batched continuously token-by-token
GPU stays busy
Throughput improves

PagedAttention#

PagedAttention manages KV cache memory more efficiently, similar in spirit to virtual memory paging. This helps serve many requests without wasting huge blocks of GPU memory. vLLM highlights PagedAttention as a core reason for its throughput.

Prefix caching#

If many users share the same system prompt or long context, prefix caching can reuse previously processed tokens.

Use cases:

Same company policy document
Same system prompt
Same RAG instruction prefix
Same coding repository summary

Tensor parallelism#

When one model is too large for one GPU:

vllm serve meta-llama/Llama-3.1-70B-Instruct \
  --tensor-parallel-size 4

Meaning:

Split model across 4 GPUs.

Production reverse proxy#

Typical production layout:

User
→ Nginx / Caddy / API Gateway
→ Auth / rate limit
→ vLLM server
→ GPU

Do not expose an unauthenticated local LLM server directly to the public internet.

9.10 Benchmarking#

vllm bench latency \
  --model Qwen/Qwen2.5-1.5B-Instruct \
  --input-len 128 \
  --output-len 128

vllm bench serve \
  --model Qwen/Qwen2.5-1.5B-Instruct \
  --host localhost \
  --port 8000 \
  --num-prompts 100

Measure:

TTFT
tokens/sec
requests/sec
p50 latency
p95 latency
p99 latency
GPU memory
GPU utilization
error rate

9.11 Clean uninstall#

Python environment:

deactivate
rm -rf .venv

Package only:

pip uninstall -y vllm

Docker:

docker rm -f vllm-server 2>/dev/null
docker image rm vllm/vllm-openai:latest

Optional model cache cleanup:

rm -rf ~/.cache/huggingface/hub

9.12 Real developer uses#

Use vLLM for:

- Internal company LLM API
- RAG backend serving
- Multi-user chat applications
- GPU inference cluster
- OpenAI-compatible replacement
- Batch summarization
- Evaluation pipelines
- Production load testing

9.13 Pros and cons#

Pros:

- Best production throughput
- OpenAI-compatible
- Docker-friendly
- Strong batching and KV-cache management
- Supports many model architectures
- Production monitoring/deployment friendly

Cons:

- More infrastructure knowledge needed
- Usually needs Linux + GPU
- More complex than Ollama/LM Studio

Recommended video/course: vLLM Serving Tutorial: High-Performance LLM Inference or DeepLearning.AI’s vLLM course.

Important Q&A#

Q: Can I run vLLM on a CPU or MacBook? A: vLLM is primarily designed for high-performance Nvidia/AMD GPUs. If you are on a CPU or a Mac, you are much better off using llama.cpp or MLX.

Q: What does -ngl 999 do in llama.cpp? A: ngl stands for “Number of GPU Layers”. Setting it to a very high number like 999 tells llama.cpp to try to offload all parts of the neural network to the GPU. If your GPU memory fills up, it will offload whatever it can and run the rest on the CPU.

Q: Why use vLLM over Ollama in production? A: Ollama processes one request at a time sequentially. vLLM uses continuous batching and PagedAttention to process hundreds of requests simultaneously, giving you vastly higher throughput and GPU utilization.

Final revision checklist#

[ ] I know how to run a GGUF model using `llama-cli`.
[ ] I understand how `-ngl` offloads layers to the GPU in `llama.cpp`.
[ ] I know how to start the `llama.cpp` local API server.
[ ] I understand when to use `vLLM` (production, GPUs, high traffic).
[ ] I can explain continuous batching and PagedAttention in simple terms.
