Similarity Search#
You have a million embeddings. A user queries arrive. Brute-force cosine similarity over 1M × 1536-dim vectors takes seconds. Approximate Nearest Neighbor (ANN) indices make it milliseconds — with only a small loss in recall.
The Problem: Brute-Force Doesn’t Scale#
import numpy as np
import time
n_docs = 1_000_000
dim = 1536
# Simulate 1M document embeddings
corpus = np.random.randn(n_docs, dim).astype(np.float32)
corpus /= np.linalg.norm(corpus, axis=1, keepdims=True) # normalize
query = np.random.randn(dim).astype(np.float32)
query /= np.linalg.norm(query)
# Brute force
start = time.time()
similarities = corpus @ query
top5 = np.argsort(similarities)[::-1][:5]
elapsed = time.time() - start
print(f"Brute force: {elapsed*1000:.0f}ms for {n_docs:,} docs")
# → ~1,200ms on CPU — too slow for a web APIANN indices trade a small amount of accuracy for 100–1000x speed:
| Method | Speed (1M docs) | Recall@10 | Memory | Use Case |
|---|---|---|---|---|
| Brute force | ~1,200ms | 100% | O(n×d) | < 10k docs |
| FAISS IVF | ~5ms | 95% | O(n×d) | 100k–10M docs |
| HNSW | ~1ms | 98% | O(n×d × 1.1) | 100k–5M docs |
| FAISS PQ | ~2ms | 85% | O(n × m/8) | > 10M docs (compressed) |
FAISS (Facebook AI Similarity Search)#
FAISS is the most widely used library for similarity search. It supports CPU and GPU, multiple index types, and handles billions of vectors.
uv add faiss-cpu # CPU version (for most use cases)
# uv add faiss-gpu # if you have a CUDA GPUFlat Index (Exact, for < 100k docs)#
import faiss
import numpy as np
dim = 1536
# Build index
index = faiss.IndexFlatIP(dim) # IP = inner product = cosine on normalized vectors
# Alternative: faiss.IndexFlatL2(dim) for L2 distance
# Add embeddings (must be float32, normalized for cosine)
corpus_np = np.array(embeddings, dtype=np.float32)
faiss.normalize_L2(corpus_np) # normalize in place
index.add(corpus_np)
print(f"Index size: {index.ntotal:,} vectors")
# Search
query_np = np.array([query_embedding], dtype=np.float32)
faiss.normalize_L2(query_np)
k = 5 # top-5 results
distances, indices = index.search(query_np, k)
for rank, (dist, idx) in enumerate(zip(distances[0], indices[0])):
print(f"[{rank+1}] score={dist:.4f} doc_id={idx}")IVF Index (Inverted File — for 100k–10M docs)#
IVF clusters vectors into Voronoi cells. At search time, only nearby cells are searched:
import faiss
import numpy as np
dim = 1536
n_docs = 500_000
# IVF parameters
n_clusters = int(np.sqrt(n_docs)) # rule of thumb: sqrt(n_docs)
n_probe = 32 # how many clusters to search at query time
# higher = more accurate but slower
# Build index
quantizer = faiss.IndexFlatIP(dim)
index = faiss.IndexIVFFlat(quantizer, dim, n_clusters, faiss.METRIC_INNER_PRODUCT)
# Training is required for IVF (learns cluster centers)
print("Training index...")
train_data = corpus_np[:min(n_docs, 100_000)] # train on a subset if needed
index.train(train_data)
# Add all vectors
index.add(corpus_np)
index.nprobe = n_probe
print(f"Index trained on {train_data.shape[0]:,}, total: {index.ntotal:,}")
# Search is much faster now
distances, indices = index.search(query_np, k=5)IVFPQ Index (Compressed, for > 10M docs)#
Product Quantization compresses vectors from 1536 floats (6144 bytes) to just 96 bytes per vector:
import faiss
dim = 1536
n_clusters = 1024
m = 96 # number of sub-quantizers (must divide dim)
# 1536 / 96 = 16 floats per sub-vector
bits = 8 # 8 bits per code = 256 centroids per sub-quantizer
quantizer = faiss.IndexFlatIP(dim)
index = faiss.IndexIVFPQ(quantizer, dim, n_clusters, m, bits, faiss.METRIC_INNER_PRODUCT)
index.train(corpus_np)
index.add(corpus_np)
index.nprobe = 32
# Memory: 96 bytes per vector vs 6144 bytes (64x compression!)
print(f"Memory per vector: {m} bytes (vs {dim * 4} bytes uncompressed)")Save and Load FAISS Index#
# Save
faiss.write_index(index, "my_index.faiss")
# Load
index = faiss.read_index("my_index.faiss")
index.nprobe = 32 # re-set nprobe after loadingHNSW (Hierarchical Navigable Small World)#
HNSW is often faster than FAISS IVF for medium-scale search and easier to use. It’s the default index in ChromaDB, Qdrant, and Weaviate.
uv add hnswlibimport hnswlib
import numpy as np
dim = 1536
max_elements = 100_000
# Build index
index = hnswlib.Index(space="cosine", dim=dim)
index.init_index(
max_elements=max_elements,
ef_construction=200, # higher = better quality, slower build
M=16, # number of edges per node; 16 is good default
)
# Add items with IDs
ids = np.arange(len(embeddings))
corpus_np = np.array(embeddings, dtype=np.float32)
index.add_items(corpus_np, ids)
# Set ef for search (higher = more accurate, slower)
index.set_ef(50) # ef >= top_k
# Search
query_np = np.array([query_embedding], dtype=np.float32)
labels, distances = index.knn_query(query_np, k=5)
for rank, (label, dist) in enumerate(zip(labels[0], distances[0])):
print(f"[{rank+1}] doc_id={label}, distance={dist:.4f}")
# Save and load
index.save_index("hnsw_index.bin")
index_loaded = hnswlib.Index(space="cosine", dim=dim)
index_loaded.load_index("hnsw_index.bin", max_elements=max_elements)HNSW Parameters Guide#
| Parameter | Default | Effect |
|---|---|---|
M | 16 | Edges per node. Higher = better recall, more memory |
ef_construction | 200 | Build quality. Higher = slower build, better index |
ef (search) | 50 | Search quality. Higher = slower search, better recall |
For most use cases: M=16, ef_construction=200, ef=50 gives >95% recall.
Putting It Together: A Complete Search System#
import faiss
import numpy as np
import json
from pathlib import Path
from openai import OpenAI
class EmbeddingSearchIndex:
def __init__(self, dim: int = 1536, use_hnsw: bool = True):
self.dim = dim
self.documents: list[str] = []
self.metadata: list[dict] = []
if use_hnsw:
import hnswlib
self.index = hnswlib.Index(space="cosine", dim=dim)
self._type = "hnsw"
else:
self.index = faiss.IndexFlatIP(dim)
self._type = "faiss"
self.client = OpenAI()
def _embed(self, texts: list[str]) -> np.ndarray:
response = self.client.embeddings.create(
model="text-embedding-3-small",
input=texts,
)
embs = np.array([r.embedding for r in sorted(response.data, key=lambda x: x.index)], dtype=np.float32)
faiss.normalize_L2(embs)
return embs
def build(self, documents: list[str], metadata: list[dict] = None, batch_size: int = 100):
self.documents = documents
self.metadata = metadata or [{} for _ in documents]
if self._type == "hnsw":
self.index.init_index(max_elements=len(documents), ef_construction=200, M=16)
print(f"Embedding {len(documents)} documents...")
for i in range(0, len(documents), batch_size):
batch = documents[i:i+batch_size]
embs = self._embed(batch)
if self._type == "hnsw":
self.index.add_items(embs, np.arange(i, i+len(batch)))
else:
self.index.add(embs)
print(f" {min(i+batch_size, len(documents))}/{len(documents)}", end="\r")
print(f"\nIndex built: {len(documents)} documents")
if self._type == "hnsw":
self.index.set_ef(50)
def search(self, query: str, top_k: int = 5) -> list[dict]:
q_emb = self._embed([query])
if self._type == "hnsw":
labels, distances = self.index.knn_query(q_emb, k=top_k)
results = [
{"text": self.documents[i], "score": 1 - float(d), "metadata": self.metadata[i]}
for i, d in zip(labels[0], distances[0])
]
else:
distances, indices = self.index.search(q_emb, top_k)
results = [
{"text": self.documents[i], "score": float(d), "metadata": self.metadata[i]}
for d, i in zip(distances[0], indices[0])
if i >= 0
]
return results
# Usage
search = EmbeddingSearchIndex(use_hnsw=True)
search.build(
documents=course_materials,
metadata=[{"week": w, "topic": t} for w, t in zip(weeks, topics)],
)
results = search.search("How do I add authentication to FastAPI?", top_k=3)
for r in results:
print(f"Score: {r['score']:.3f} | Week {r['metadata']['week']} — {r['text'][:100]}")Choosing the Right Index#
Number of vectors?
< 10,000 → Brute force (IndexFlatIP) — simplest, exact
< 500,000 → HNSW (hnswlib) — fast, good recall, easy
< 5M → FAISS IVF — fast, good recall, needs training
> 5M → FAISS IVFPQ — compressed, approximate
Memory constrained?
→ FAISS PQ (64x compression, lower recall)
Need GPU acceleration?
→ faiss-gpu, supports all index types on CUDA
Need to update index (add/delete)?
→ HNSW (supports add); FAISS requires rebuilding for deletes
Production scale search?
→ Use a vector database (Qdrant, ChromaDB, Weaviate) — they wrap these
indices with persistence, filtering, and API accessSummary#
| Library | Index Type | Speed | Recall | Memory | Update |
|---|---|---|---|---|---|
faiss (Flat) | Exact | Slow | 100% | High | ✅ Add |
faiss (IVF) | Cluster | Fast | 95% | High | ✅ Add |
faiss (IVFPQ) | Compressed | Fast | 85% | Low | ✅ Add |
hnswlib | Graph | Fastest | 98% | Medium | ✅ Add |
annoy | Tree | Medium | 90% | Medium | ❌ Rebuild |
